| INPUT | |
|---|---|
| Voltage Range | 230V AC ± 10% |
| Frequency Range | 50Hz, Single Phase |
| Power Factor | 0.95/230VAC at full load |
| Efficiency | 95% |
| OUTPUT - SINGLE CHANNEL | |
| DC Voltage | 0 to 30V (Variable) |
| Rated Current | 0 to 10A (Variable) |
| TECHNICAL SPECIFICATION | |
| PROTECTION Overload / Short Circuit | Ripple & Noise <10mVrms |
| Operating Temperature 0ºC - 50ºC | Storage Temperature 0ºC to 65ºC |
| Regulation CV Mode Line & Load regulation better than ±0.05% | Regulation CC Mode Line & Load regulation better than ±0.1% |
| Stability After 8Hrs 0.05% ±5mV | Transient Recovery 50µs |
| Indications 3Digit LED Digital meters for Voltage & Current, Accuracy: 0.5%±2 Counts | Output Control Course and Fine Single turn Potentiometers for V & I |
| FEATURES | |
| Good Regulation | Low Ripple & Noise |
| Constant Voltage/Current limited | Continuously Variable Voltage |
| Continuously Variable maximum Current limit from 10% to 110% of full load | Electrically Floating output. Can be floated up to 300V off ground |
| LED indication for O.L. | Soft start Circuit |
| Accessories: User Manual with Warranty Certificate & Q.C. Test report. | |
| RUGGED AND AESTHETIC MECHANICAL AND ELECTRICAL DESIGN | |
